MDA 2208-A+C mini current control electric fixtured spindle

Code P207778

MDA 2208-A+C mini current control electric fixtured spindle

Code P207778

Compact and easy to integrate, the MDA2208-A+C mini telescopic spindle is designed for microtorque tightening operations (from 0.089 to 0.441 Nm) requiring repeatability (3%) and traceability of tightening torques. It is dedicated to applications in the fields of watchmaking, eyewear, microelectronics, luxury leather goods, dental prosthesis, etc.

Technical details
Benefits
Product description
Associated products
Resources

Technical details

Type of screwdriver

Current control electric fixtured spindle

Min Torque

0.09 Nm

Max Torque

0.45 Nm

Min speed rotation

100 tr/min

Maxi speed rotation

950 tr/min

Drive Size

1/4" F/Hex

Weight

0.33 kg

Shape

Fixtured spindle

Starting system

Remote

Power

Electric

Functionalities

ESD,

Torque programmable,

Counting,

Network communication

Suitable controller

MDC-22

Benefits

Quality of manufacture

3% precision regardless of tightening elasticity

Robustness

Maxxon Motor made in Switzerland

Easy integration

Flange mounting and aluminum body

Industry 4.0

    Traceability of tightening torques via Ethernet
    Visualization of the curves
    Anti-error system

Product description

Easy to adjust thanks to its automatic programming mode via its color touch screen or PC software, it allows you to optimize your operating speed.
15 torque / angle or angle / torque tightening strategies of 10 steps each are available.
The use in automatic sequence mode makes it possible to carry out a complete tightening cycle with counting and accessory control functions (presence sensor, pick to light, alarm, etc.) thanks to the assignable inputs / outputs.
The screw curves are visualized in real time.
Data are stored and transferable via Ethernet or RS232.
The telescopic stroke is 10 mm.
It is delivered without a tool cable.
